20 mhz tcxo SMD5032

Frequency: 20MHz
Frequency Tolerance: ±1ppm
Frequency Stability: ±0.28ppm
Operating Supply Voltage Range: 3.135V ~ 3.465V

Explore the 20 mhz tcxo, offering high stability with temperature compensation, ideal for GPS, IoT, and precision instruments. Compact SMD package ensures reliable performance in demanding applications.

1. NOMINAL AND MAXIMUM RATINGS, OPERATING AND STORAGE CONDITIONS

	Parameters	Symb.	Min.	Typ.	Max.	Unit	Conditions /Remarks
1	Nominal frequency	F_N	20.000			MHz
2	Maximum supply voltage	V_Max.	-0.3		+4.0	V_DC	Between V_CC and GND
3	Operating Supply Voltage Range	V_cc	3.135	3.30	3.465	V_DC
4	Output Load Resistance	RL	9	10	11	kΩ	Clipped sine wave output
5	Output Load Capacitance	CL	9	10	11	pF	Clipped sine wave output
6	Operating Temperature Range	T_oP	-40	+25	+85	℃	Note 1
7	Storage Temperature Range	T_sT	-40		+85	℃

Note 1: over the whole range, the unit stays within all relevant parameter limits as specified under point 2

2. ELECTRICAL PARAMETER LIMITS

	Parameters	Symb.	Min.	Typ.	Max.	Unit	Conditions /Remarks
1	Frequency Tolerance	△f/F_N	-1.0		+1.0	ppm	Offset from nominal at +25°℃
2	Frequency Stability	△f/F_RFL	-0.28		+0.28	ppm	Note 1
3	Frequency VS Voltage Changes	△f/F_V	-0.1		+0.1	ppm	Vcc±5% at +25℃
4	Frequency VS Load Changes	△f/F_L	-0.1		+0.1	ppm
5	Aging 20 years	△f/F_A1	-3.0		+3.0	ppm	at +25℃
6	Output Amplitude Voltage Level	V_P-P	0.8			V_AC	Clipped sine wave
7	Output Symmetry (Duty Cycle)	DC	45		55	%	GND level (DC cut)
8	Phase Noise	L_RMS		-98		dBc/Hz	at 10Hz offset /at +25℃
				-125			at 100Hz offset/at+25℃
				-145			at 1kHz offset /at +25℃
				-150			at 10kHz offset /at +25℃
				-155			at 100KHz offset /at+25℃
9	Startup Time	t_STRT			2.0	ms	Vp-p reach > 90% of amplitude
10	Current Consumption	I_CC			3.5	mA
