Center Frequency(fo)(MHz): 10.700±0.030
3dB Bandwidth(kHz): 180±40
20dB Bandwidth(kHz) max: 470
Insertion Loss (dB) (at minimum loss point): 4.5±2.0
The 10.7 MHz ceramic filter offers a center frequency of 10.700±0.030 MHz, with a 3dB bandwidth of 180±40 kHz and a 20dB bandwidth of up to 470 kHz. Ideal for RF applications, this filter provides excellent frequency stability and selectivity for high-performance communication systems.
Items | Content |
Withstanding Voltage (V) max. | 50 (DC，1min) |
Insulation Resistance Ri,（MΩ）min. | 100 （10V，1min） |
Operating Temperature Range (℃) | -20～+80 |
Storage Temperature Range (℃) | -40～+85 |
Items | Content |
Center Frequency(fo)(MHz) | 10.700±0.030 |
3dB Bandwidth(kHz) | 180±40 |
20dB Bandwidth(kHz) max | 470 |
Insertion Loss (dB) (at minimum loss point) | 4.5±2.0 |
Ripple (dB) max (within 3dB Bandwidth) | 1.0 |
Spurious Response (dB) min(9MHz-12MHz) | 30 |
Input/Output Impedance(Ω) | 330 |
Temp. Characteristic | ±0.5% (–20℃ to 80℃ ) |
Parts shall be tested under the condition ( Temp.：20±15℃,Humidity ：65±20% R.H.) unless the standard condition(Temp.：25±2℃,Humidity ：65±5% R.H.) is regulated to measure.
