HC-49SMD

Frequency: 11.059200MHz
OPERATION TEMPERATURE RANGE: -20~70℃
LOADING CAPACITANCE (CL) ： 20PF
FREQUENCY TOLERANCE: ±20ppm/Max at 25±2℃

Achieve accurate frequency control with our HC-49SMD crystal resonator. Designed for reliable performance in compact electronic devices, this surface-mount quartz crystal provides precise oscillation and exceptional stability across various applications, including communication systems and timing circuits. Trust our crystal resonator for consistent performance in your electronic designs.

Type	HC-49USM
Frequency range	3.2-100.00Mhz
Frequency Tolerance @25C	±10ppm to ±50ppm
Freuquency Drfit	±10ppm to ±50ppm
Operating temperature range	-20~70C /-40~85C
Storage temperature range	-40~85C/ -55 ~+125
Aging(25C)	±3ppm/Year Maximum
Shunt capacitance(C0)	7pF maximum
Drive level	100uW typical
Insulation rsesistiance	500 ohms minimum @D.C 100V
Load capacitance	Suggest by customer
